As one of the basic applications of the power unit, the electric stacker can make more changes in the control mode according to the needs of customers.
1. High pressure gear oil pump / DC motor / Single acting
2. All electric
| Model | DC-F10-3.7/E-2.2/24/2900-14H-D |
| Voltage | DC 24V |
| Power | 2.2kW |
| Speed | 2900rpm |
| Disp. | 3.7 cc/r |
| Pressure | 16 MPa |
| Volume | 14L |
| Size | P, T: G3/8 |
GRH electric stacker power packs are widely used in aerial work platform and automobile tail gate.
