This product provides the lifting and closing functions of the large and small levelers for the hydraulic dock levelers, and it can control two sets of single-acting cylinders.
1. High-pressure gear oil pump / AC motor / Multi-valve control
2. Iron tank
| Model | AC-F32-3.2/D-1.5/240/1440/**-6H-C |
| Voltage | AC 240V |
| Power | 1.5kW |
| Speed | 1440rpm |
| Disp. | 3.2 cc/r |
| Pressure | 10 MPa |
| Volume | 6L |
| Size | A, B, M: G1/4 |
GRH dock leveler power packs 1 are widely used in aerial work platform and automobile tail gate.
